Thermostat Options
 |
DA/RA Discharge/Return Air Sensor Option EXL03020 |
| The DA or RA option adds a 10K type II sensor for monitoring the discharge or return air temperature on ExactLogic models that support the DA or RA option (will be listed on the cut sheet).
|
|
|
|
Your Price: $12.96 |
 |
|
 |
Backplate release pencil EXL04013 |
| The Backplate Release pencil allows for easy removal of the ExactLogic covers. The pencil is applied to the backplate tabs prior to attaching the cover, this allows for easier removal of the cover in the future. If you would like to restore the tamperproof feature just wipe the lower tabs off prior to assembling the cover. Look for instructions on how to properly remove the cover on our resources page. |
|
|
|
Your Price: $2.88 |
|
|
 |
Communications Connection Plug with Extension EXL03012 |
| The Communications Connection Plug is designed to fit into the recessed communications port of the ExactLogic controllers to allow a temporary connection to the MS/TP communications trunk from up to 3' away. The extended connector allows for easy connection and alignment with the internal port. |
|
|
|
Your Price: $27.00 |
|
|
 |
EXL04030 Nema 4X Enclosure 8x6x3 windowed |
|
Non-Metallic Enclosure for ExactLogic BACnet communicating thermostats
- 8" tall by 6" wide by 3" deep
- Back Panel
- Clear Cover
- Integrated Latch with opening for external lock
- Polycarbonate
|
|
|
|
Your Price: $110.04 |
|
|
 |
Thermostat Horizontal Cover Plate for 2x4 handy box EXL04011 |
- This Horizontal Cover Plate will cover the opening from a 2x4 handy box
- 5 7/8" x 7 1/2"
- Horizontal holes at 3 1/4"
- Vertical holes at 3 1/4"
- Made of Opaque White Plexiglas material with a gloss finish
|
|
|
|
Your Price: $14.40 |
|
|
 |
Thermostat Replacement Backplate EXL04010 10-Pack |
| The Replacement Backplates come in packages of 10.
|
|
|
|
Your Price: $24.84 |
|
|
 |
Thermostat Replacement Case EXL04012 10-Pack |
| The Replacement Cases come in packages of 10.
|
|
|
|
Your Price: $39.24 |
|
|
 |
EXL03013 24Vac or dc Relay 20A 120-277V |
| The Low Voltage Relay is controlled by a 24Vac or 24Vdc power source and provides Normally Open (NO) and Normally Closed (NC) contacts rated at 20A at up to 277 Vac. The Relay is used to interface from the ExactLogic low voltage Binary Outputs (BOs) to control Line Voltage devices - 120Vac to 277Vac. |
|
|
|
Your Price: $21.60 |
|
|
 |
EXL03018 Relay 9-40Vdc coil with 7A at 24Vdc or 10A at 120VAC contracts |
| The Low Voltage Relay is used to convert an ON/OFF Analog Outputs (0-10vdc) to Binary Outputs (Dry Contacts). The relay is controlled by a 9-40Vdc power source and provides Normally Open (NO) and Normally Closed (NC) contacts rated at 10A at up to 120 Vac or 7A at 24Vdc. |
|
|
|
Your Price: $16.92 |
|
|
|
EXL03019 24Vac or 120Vac Relay with 7A at 24VDC or 10A at 120VAC Contacts |
| The Low Voltage Relay is used to connect the ExactLogic Binary Output (BO) contacts to control line voltage loads. The relay is controlled by a 24Vac power source and provides Normally Open (NO) and Normally Closed (NC) contacts rated at 10A at up to 120 Vac or 7A at 24Vdc. |
|
|
|
Your Price: $21.24 |
|
|
|
